ResinRock XL5

Resin-Fortified, Increased-Expansion Die Stone

ISO Type 5

RESINROCK XL5┬áhas the same smoothness and high abrasion resistance you’ve come to appreciate in ResinRock. However, this ISO Type 5 die stone gives you increased expansion to compensate for shrinkage of vinyl polysiloxane and other rubber-based impression materials.

Available in four colors: green, blue, pink and ivory. Pink, blue, and green provide excellent contrast to casting waxes. The neutral tone of ivory complements all ceramic materials.


  • Ideal for use with rubber-based impression materials which may contract over time
  • Increased setting expansion of 0.20%
  • Resin-fortified for advanced abrasion resistance
  • Smooth, dense surface for superior detail reproduction
  • Thixotropic, creamy mix stacks and vibrates easily into impression

Please note the use of Gypsum Hardener is not recommended with this product

Physical Properties

Water/Powder Ratio
20 mL/100 g
Working Time
5 - 7 minutes
Setting Time
10 minutes
Setting Expansion
Compressive Strength, Wet (1hr.)
7,000 psi (49 MPa)
Compressive Strength, Dry (48 hrs.)
11,000 psi (76 MPa)
Item No. Description
330017 ResinRock XL5 Blue 33#/15KG
330018 ResinRock XL5 Green 33#/15KG
330019 ResinRock XL5 Ivory 33#/15KG
